Сканер штрих-кодов POS модели BSWNL-3000-RAT с последовательным/RS232/COM-портом для супермаркетов.

Сканер штрих-кодов POS модели BSWNL-3000-RAT с последовательным/RS232/COM-портом для супермаркетов.

 Pay attention before you place order:

***Above offer for Serial interface, with stand& auto sense, with DC adaptor power supply.

***1D barcode scanner.

***Default color is black..

***About remote areas: please make sure buyer left correct post code with corresponding city name. If buyer’s address is remote area, please buy a “remote area charge” (https:/store/product/20170512-Remote-area-extra-delivery-shipping-cost/433898_32810924493.html?spm=2114.12010615.0.0.9dxpqo ) service when place order and leave message to us. If nothing left for a remote area address, we will not ship goods.

***About commercial invoice: If no special request, we will put an invoice with our stamp into your package. If you need the invoice for customer clearance, pls contact our sales by mail.

Link for different interfaces:

Model number

Description

Buying link

BSWNL-3000-U

USB port, without stand, without auto sense

https:/store/product/BSWNL-3000-U-1D-Laser-Barcode-Scanner-High-Speed-Good-Quality-USB-Interface/433898_32810289580.html?spm=2114.12010615.0.0.xL7CdO

BSWNL-3000-UAT

USB port, with stand, with auto sense

https:/store/product/BSWNL-3000-UAT-USB-Bar-Code-Scanner-Auto-Scan-With-Stand-For-POS-System/433898_32810998627.html?spm=2114.12010615.0.0.TBzlHa

BSWNL-3000-R

Serial port, without stand, without auto sense

https:/store/product/BSWNL-3000-R-Serial-Port-1D-Laser-Barcode-Scanner-COM-Communicate-DC-Power-Supply/433898_32811412289.html?spm=2114.12010615.0.0.EoSJlQ

BSWNL-3000-RAT

Serial port, with stand, with auto sense

https:/store/product/BSWNL-3000-RAT-POS-Barcode-Scanner-1D-Serial-RS232-COM-Port-Reader-For-Supermarket/433898_32811294281.html?spm=2114.12010615.0.0.QJmH2M

Specification:

Features

1.32 bits high performance CPU

2.Diversity of interface

3.Flexible configuration

4.Ultra comfort design

5.Best value price

6.Diversified customized features

7.Achieving one-to-many communications (one PC/PLC host to many barcode scanners)

8.Complement checking code for barcode data and command

9.Creative user defined barcode technology

Benefits

1.Excellent performance in decoding and error correcting capacity

2.Support RS232, USB keyboard interface

3.Customized configuration with best performance

4.Perfect human engineering design, ultra comfort with lifetime use

5.32 bits CPU performance with only 8 bits CPU price

6.Great match for customer applications, greatly improve work efficiency

7.Good for applications as multiple barcode scanners linked to the same network

8.More secure for data and command transfer

9.User defined barcode binding with unique ID barcode scanner

Application and Solution

Clothing, retail chain store, warehouse management, e-business, commercial retail, logistics express and file management, etc

Basic Product Specifications

Operating indicators

Visual

1 LED(blue)

Non-visual

Buzzer

Communications

Rs232   USB(Ver. 1.1 HID Keyboard)

Power

Voltage requirement

5V± 10%

Current consumption

85mA (typical use),max.150mA

Barcode scanner Optics

Light source

650nm visible laser diode

Scan method

Bi-directional scanning

Scan rate

100scans/sec

Trigger mode

Manual, multiple read, auto-trigger, serial software trigger

Reading pitch angle

(pitch)-50 to 0°, 0 to +50°
(skew)-65 to 0°, 0 to +65°
(tilt)-35 to 0°, 0 to +35°

Curvature

R>15 mm (EAN8),R>20 mm (EAN13)

Min. resolution

PCS 0.9: 0.101 mm / 4 mil, Min. PCS value: 0.35

Physical

Dimensions

90.5 x 69.8 x 160 mm
3.56 x 2.75 x 6.30 in (d x w x h)

Weight body

146g/ 5.15 oz (excl. cable)

Case

PC, Black or Grey

Durability

Temperature

 -20°to 65°C / -4°to 149°F(operation)
 -30°to 70°C /-22°to 158°F(storage)

Humidity

20 - 85% (operation), 20 - 90% (storage)

Ambient light immunity

Fluorescent 3000 lx max, Direct sun 50,000 lx max, Incandescent 3000 lx max

Drop test

1.5m/5ft drop onto concrete surface

Protection rate

IP 54

Regulatory & Safety

Product compliance

CE, FCC, IEC 60825-1 Class 2, GB7247.1-2001

Enclosed items

Cable(USB,RS232,RS485), User Guide, DC power supply (RS232,RS485)

Supported Symbologies

Barcode(1D)
EAN13,EAN8,UPC-A,UPCE,CODABAR(NW-7),CODE39,
CODE93,INTERLEAVED_2OF5,STANDARD_2OF5,MATRIX_2OF5,
CODE128,EAN128(GS1-128),CODE11,CHINESE_POST

Depth of field

PCS 0.9 Code 39
70 - 650 mm / 2.76 - 25.59 in (1.0 mm / 39 mil)
50 - 420 mm / 1.97 - 16.54 in (0.5 mm / 20 mil)
50 - 260 mm / 1.97 - 10.24 in (0.25 mm / 10 mil)
50 - 150 mm / 1.97 - 5.91 in (0.15 mm / 6 mil)
60 - 120 mm / 2.36 - 4.72 in (0.127 mm / 5 mil)
50 - 110 mm / 1.97 - 4.33 in (0.101 mm / 4 mil)
